FOCUS STICKER LABELING MACHINE is one of the toppest dental floss packaging line,Dental Floss Winding Machine in China.During these years of exporting , FOCUS STICKER LABELING MACHINE now has rich experience in the worldwide markets

  • Main Electrical Configuration
  • For Ref
Main specifications and technical parameters
• Servo motor total power: 800W;
• Voltage: 220V 50 ~ 60HZ
• Dimensions: 3000mm × 1500mm × 1300mm ;
• Weight 150Kg

Working condition and application of environmental
a. Operating temperature: 20 to 30 ℃
b. Operating Humidity: 30% ~ 80% RH
c. The working environment: non-inflammable and explosive gas and dust

No Name Model Number Brand
1 PLC Control system TP04G-AL-C 1 set Taiwan DELTA
2 Touch screen DVP14SS211R 1 set Taiwan DELTA
3 Servo motor TL-A230P-BT32AA 2 sets American AB
4 Servo driver 2071-AP4 2 sets American AB
5 24V DC electrical source PMC-240751AA 1set Taiwan DELTA
6 Relay RX2E1M2C 1 set France Schneide

  • Drawing
