FOCUS STICKER LABELING MACHINE is one of the toppest online printing and labeling machine,Online Printing Labeling Machine,Automatic labeling machine in China.During these years of exporting , FOCUS STICKER LABELING MACHINE now has rich experience in

  • Parameters
  • Main Electrical Configuration
  • For Ref
Model RPLM-ALX924
Labeling way Online printing and labeling
Operating Direction From right to left
Print and peal speed(mm/second) DPM and PEM 4″/5″:50-400(mm/second)
/6″:50-300 (mm/second)
Printing length 10-1000mm
Printing Width ALX924:106mm
Ribbon save function 6mm No print area
material specification Self-adhesive sticker
Labeling Speed(pcs/min) ≤70 ( Depends on the size of label objects)
Labeling Precision (mm) ±1mm (Depends on flatness of label objects surface)
communication port Standard RS232、RS485
Control port Reserved
Applicable of label(mm) Width ≤50、length ≤100
Inner diameter of label roll 76mm
Outer diameter of label roll 350mm (max)
Conveyor for top labeling machine Belt
Conveyor for round labeling machine chain plate
Total motor power(w) 500
Voltage 380V 60HZ
air source 0.6 mpa
No Name Model Unit Brand
1 PLC control system 6ES7212-1A 1 Set SIEMENS
2 Touch-screen 6AV6648-01A 1 Set SIEMENS
3 Photoelectric sensor PRK3B-6.7 1set German Leuze
4 cylinder stator 16X50 1set SMC
5 print engine ALX924 1set AVERY
6 Conveyor motor
(round product labeling)
370W 1set Switzerland ABB
7 Conveyor motor
(top labeling)
90W1:30 1set German JSCC
8 Separate objects motor 40W1:30 1set German JSCC
