SKILT focus sticker labeling machine since 1998,professional bottle top and side surface,top & wrap around label applicator manufacturer.

  • INTRODUCTION
  • CONFIGURATION
  • PARAMETER
  • OPTIONAL
  • SERVICE



         Application:


  Labeling type compatible:

  One side labeling • top & side labeling • Square bottle Multi sides labeling • Wrap-around labeling (optional)

  Product specifications: Rectangular, flat-arched to oval, cylindrical, free-standing ;


  Optional Function :

  1.Infeeder and Outfeeder turntable in different size ;


         2.Camera with labeling accuracy checking function  ;


  3.Add 3rd applicator for one more labeling position ;


  4.Printer deivce,  printing date and batch number on labels directly.



No Name Brand
1 PLC control system SIEMENS
2 Touch-screen SIEMENS
3 Labeling engine Servo motor PANISONIC & GERMAN NOVEXX
4 Check opaque label sensor German Leuze
5 Ccheck bottle sensor Japan KEYENCE
6 Main transport motor Switzerland ABB
7 Press bottle motor German JSCC
8 Separate bottle Motor German JSCC
Model DPM-SLM-A & DPM-SLM-ALS204
Driving Model
Servo system & German Novexx
Label material
Self-adhesive sticker, opaque or transparent label
Yieldpcs/min
50-180pcs/min
Suitable label size
L:10-250mm,H:10-200mm
Suitable bottle size
W:(Diameter): 20-90mm , H:30-300mm
Voltage
110V/220V/380V
Machine size
2400(L)×  1500(W)×  1500 (H) mm

1.German NOVEXX labeling engine


2. Printer device

Thermal transfer printing way , printing date and batch number on labels.

Machine with TWO year warranty

Supply operation training for client workers

If with quality problem, provide technical support and supply wearing parts timely .

④ Range experienced engineer come to client company for installation
