SKILT FOCUS STICKER LABELING MACHINE SINCE 1998,is one of the toppest top side labeling machine,square cans labeling machien,square jar labeling machine in China.

  • INTRODUCTION
  • CONFIGURATION
  • PARAMETER
  • Optional
  • SERVICE


       Labeling type compatible:

One side labeling • top & side labeling • Square bottle Multi sides labeling • Wrap-around labeling (optional)

Product specifications: Rectangular, flat-arched to oval, cylindrical, free-standing ;


Optional Function :

1.Infeeder and Outfeeder turntable in different size ;

2.Camera with labeling accuracy checking function  ;

3.Add 3rd applicator for one more labeling position ;

4.Printer deivce,  printing date and batch number on labels directly.


No Name Brand
1 PLC control system SIEMENS
2 Touch-screen SIEMENS
3 Labeling engine Servo motor panisonic & GERMAN NOVEXX
5 Check opaque label sensor German Leuze
6 Check jars sensor Japan KEYENCE
8 Main transport motor Switzerland ABB
9 Press bottle motor German JSCC
11 Separate bottle Motor German JSCC
Model DPM-SLM-A & DPM-SLM-ALS204
Driving Model
Servo system & German Novexx
Label material
Self-adhesive sticker, opaque or transparent label
Yieldpcs/min
50-180pcs/min
Suitable label size
L:10-250mm,H:10-200mm
Suitable bottle size
W:(Diameter): 20-90mm , H:30-300mm
Voltage
110V/220V/380V
Machine size
2400(L)×  1500(W)×  1500 (H) mm

1.German NOVEXX labeling engine


2. Printer device

Thermal transfer printing way , printing date and batch number on labels.

Machine with two years warranty

Supply operation training for client workers

If with quality problem, provide technical support and supply wearing parts timely .

④ Range experienced engineer come to client company for installation
