Desktop Labeling Applicator

Video

Parameters

Model	PLM-B
Driving Mode	German NOVEXX Labeling engine
Yield（pcs/min）	30-200(depends on product and label size)
Operating direction	Left or Right
Conveyor Speed（m/min）	≤40
Labeling Accuracy	±1.0 mm
The inner diameter of label roll	76 mm
The outer diameter of label roll	350 mm(max)
The suitable size of label	Width 15-110 mm length 15-300 mm
The suitable size of labeling objects	Can customized
Printer use air	5kg/cm ²
Voltage (In China)	AC220V 50/60HZ Single phase (Can customized as client need)
Power（w）	550W
Weight（kg）	260
Machine size	1800（L） 800 (W) 1500 (H) mm

Main Electrical Configuration

No	Name	Model	Unit	Brand
1	PLC control system	288-1ST20-OAAO	1 Set	SIEMENS
2	Touch-screen	648-OCC11-3AXO	1 Piece	SIEMENS
3	Labeling engine Servo motor	1FL6 034-2AF21-1AA1	1 set	SIEMENS
4	Labeling engine Drive	6SL3 210-5FB10-4UA1	1 set	SIEMENS
5	Frequency converter	6SL3210-5BB15-5UV0	1 set	SIEMENS
6	photoelectric sensor (check products)	FS-N18N	1 set	Japan KEYENCE
7	Photoelectric sensor (Check opaque label）	GS61/6.2	1 set	German Leuze
7	Photoelectric sensor (Check opaque and transparent label）	GSU 14B/66.3-S12	1 set	German Leuze
8	Main transport motor	90YS90DV22	1 set	JSCC
